Most Popular Products
Double Acting Hydraulic Cylinder
75000 INR/Unit
Product Details:
- Temperature -20C to +80C
- Pressure 160-320 bar
- Wall Thickness As per design (customizable)
- Capacity 2-40 Ton
- Material High Grade Steel / Alloy Steel
- Structure Double Acting
- Power Hydraulic
- Click to View more
X
Double Acting Hydraulic Cylinder Price And Quantity
- 1 Unit
- 75000 INR/Unit
Double Acting Hydraulic Cylinder Product Specifications
- -20C to +80C
- Hardened Chrome Plated Steel
- Hydraulic
- Polyurethane / PTFE / NBR
- 50 mm to 2000 mm
- 160-320 bar
- Double Acting
- As per design (customizable)
- High Grade Steel / Alloy Steel
- 40-120 kg (depending on model)
- 25 mm - 250 mm
- 2-40 Ton
- Standard & Custom sizes available
- 40 mm - 300 mm
- Up to 0.5 m/s
- Polished, Anti-Corrosion Coated
- Blue / Black / Customized
- Hydraulic Oil (Mineral / Synthetic)
- Up to 1.5 times working pressure
- Industrial Equipment, Press Machines, Construction Machinery
- Clevis, Flange, Trunnion
- Welded / Tie-Rod
- G1/4" to G1-1/2"
Double Acting Hydraulic Cylinder Trade Information
- Cash in Advance (CID), Cash Advance (CA)
- 10 Unit Per Month
- 30 Days
- All India
Product Description
Owing to the expertise of professionals, we are able to offer Double Acting Hydraulic Cylinder, which uses hydraulic power to both extend and retract. This cylinder has the ability to pump hydraulic fluid to both sides of the plunger. Moreover, this cylinder is also finds usage for suspension systems in cars and other vehicles as well as airplane landing gears. Double Acting Hydraulic Cylinder is checked on well-defined parameters to ensure its quality and performance. The offered cylinder is widely appreciated among our clients for its excellent features like superb performance and strong construction.
Versatile Mounting for All Applications
Choose from clevis, flange, or trunnion mounting options to suit a wide range of industrial setups. These versatile hydraulic cylinders are designed to integrate seamlessly with equipment in construction, machinery, and heavy-duty presses, ensuring secure and efficient installation.
Superior Durability and Protection
With a polished, anti-corrosion coated finish and use of high-grade steel or alloy steel, the cylinders withstand tough industrial environments. The hardened chrome-plated rods and advanced sealing materials (Polyurethane, PTFE, NBR) provide excellent resistance to wear, leakage, and harsh operating conditions.
Customizable Design for Maximum Efficiency
Every cylinder can be tailored to match your project needs-from bore and shaft diameters to stroke lengths and color options. Whether you require standard or custom dimensions or unique wall thicknesses, our cylinders can be adapted for capacities up to 40 tons and pressures to 320 bar.
FAQ's of Double Acting Hydraulic Cylinder:
Q: How do I select the right mounting style for my hydraulic cylinder?
A: The appropriate mounting style-clevis, flange, or trunnion-depends on your machinery's design and the application's movement requirements. Clevis mounts offer pivot flexibility, flanges provide sturdy fixed connections, and trunnions allow pivoting in two directions. Consult your equipment specifications to match the cylinder mount accordingly.Q: What range of applications can your double acting hydraulic cylinders support?
A: These cylinders are ideal for use in industrial equipment, press machines, construction machinery, and various automated systems requiring robust force. Their broad capacity and size options ensure compatibility with heavy loads and continuous operation in demanding environments.Q: When should I choose welded versus tie-rod cylinder types?
A: Welded cylinders are recommended for compact designs and high-pressure tasks as they offer high structural integrity. Tie-rod cylinders are preferred when easy servicing or maintenance is needed, as they can be disassembled more easily. Both types are built for reliability and extended service life.Q: Where are these hydraulic cylinders manufactured and exported from?
A: Our hydraulic cylinders are manufactured, supplied, and exported directly from India. As experienced manufacturers and exporters, we ensure high production quality and compliance with international standards.Q: What is the process for customizing a hydraulic cylinder to my specifications?
A: Simply provide details such as required stroke, bore size, shaft diameter, port size, color, and desired mounting style. Our engineering team will design the cylinder to match your operational parameters, ensuring optimal performance for your unique application.Q: How do I ensure proper usage and longevity of the cylinder?
A: Use only recommended hydraulic oils (mineral or synthetic) and maintain fluid cleanliness. Operate within specified temperature (-20C to +80C), pressure, and stroke limits. Regular inspection and timely replacement of seals and lubricants will extend service life and uphold cylinder efficiency.Q: What are the key benefits of your double acting hydraulic cylinders?
A: You benefit from robust construction, anti-corrosion protection, high customization, and adaptability to various operating conditions. These cylinders deliver powerful, consistent performance for heavy-duty applications, maximizing uptime and reliability in industrial and construction settings.Tell us about your requirement
